Product Description
Motorized XYR Alignment Stages
Production Features:
*On the common base, the xyr alignment stage with 4 transmission mechanism to ensure XYR moving in limited height
*Transmission mechanism uses crossed-roller guide
*Supply customized service to design with or without clear aperture
Model Number | JXYR6060 | JUVW1515 | JUVW2020 |
XY Travel Range | ±15mm | ±7.5mm | ±10mm |
Angle Travel Range | ±7° | ±5° | ±5° |
Table Dimension | 60mm | 150*150mm | 200*200mm |
Guide | Cross-Roller Guide | ||
Screw Lead | 2mm | ||
Stepper Motor | 28 stepper motor | ||
Material | Aluminum | ||
Surface Treatment | Black-Anodized | ||
Loading | 6kg | 20kg | 30kg |
Weight | 2.6kg | 6.2kg | 8.3kg |
Speed | 20mm/s, 10°/s | ||
Repeatability | <2μm | <3μm | |
